Plot sea level scenario data

Usage

plot_scenario(
  dat,
  cols = c("deepskyblue", "orange", "red"),
  units = "ft",
  linewidth = 1,
  caption = TRUE,
  xrng = c(2020, 2100),
  xbrk = 10,
  yrng = NULL,
  ybrk = 7
)

Arguments

dat

Input data from get_scenario().

cols

character, color palette for the lines. Default is c('deepskyblue', 'orange', 'red').

units

character, units for the y-axis. Default is 'ft'. Options are 'ft' and 'm'.

linewidth

numeric, line width. Default is 1.

caption

logical, add caption with source. Default is TRUE.

xrng

numeric, x-axis range. Default is c(2020, 2100).

xbrk

numeric, number of x-axis breaks. Default is 10.

yrng

numeric, y-axis range as two values. Default is NULL, which uses the range of the data.

ybrk

numeric, number of y-axis breaks. Default is 7.

Value

A ggplot object

Examples

dat <- get_scenario()
plot_scenario(dat)
